The EverBeing vibration isolation device is equipped with air cushion at 4 corners. Each air cushion come with auto leveller. It can automatically control the height of the air cushion. If it is too high, the auto leveller will release excessive air from the air cushion until the pre-set height. If it is too low, the auto leveller will supply sufficient air into the air cushion until the pre-set height. There are two products as described as follows. It controls the vibration source higher than 2 Hz, it come with a pair of guard rail to prevent operator's unintendedly hit by hand or body. Air Required:100 psi.
6 models available, all tables are 36 inch (915mm high) please call for further details.
Table Top version, 36 inch (915mm high) supports up to 80Kg
VT-EB4 Vibration Free Table for EB-4
VT-PE4 Vibration Free Table for PE-4
Table version, 36 inch (915mm high) supports up to 200Kg
VT-3630 Vibration Free Table for Probe Station Vibration, Air Gauge/Air Regulator
Table Dimension: 36” x 30” (915 x 762mm)
VT-4836 Vibration Free Table for Probe Station Vibration, Air Gauge/Air Regulator
Table Dimension: 48” x 36” (1215 x 915mm)
VT-6036 Vibration Free Table for Probe Station Vibration, Air Gauge/Air Regulator
Table Dimension: 60” x 36” (152.4 x 91.4cm)
VY-7236 Vibration Free Table for Probe Station Vibration, Air Gauge/Air Regulator
Table Dimension:72” x 36” (182.9 x 91.4cm)
