Stereo Microscope
​ Anti static function: stand, zoom lens tube, 10x eyepiece, auxiliary objective lens, etc. all have anti-static function. This function is very useful when observing the samples that need anti-static (such as semiconductor chips, etc.). When using this function, the microscope can be grounded through the ground socket behind the stand. Sealing function: zoom lens tube and 10x eyepiece all have sealing function. When the microscope is used in the environment with high humidity such as oil vapor and water vapor, it can still be used more conveniently. Create ergonomic design to ensure long-term comfortable operation. With the characteristics of high definition, large field of view and long working distance, it is widely used in teaching demonstration, bioengineering, it industry detection and other fields.

The stereomicroscope was continuously zoomed with a zoom ratio of 6.3:1

In the optical system, the continuous zoom range is 0.8x ~ 5x

Eyepiece magnification: 20x

Objective magnification: 2x (working distance: 34mm)

Total magnification: 16x-100x

The angle of binocular observation was 45 degrees, and the adjustment range of bipupillary distance was 52-75mm

Ring white light source and two kinds of optical fiber light source are optional

The microscope can be finely adjusted in XY direction with an adjustment range of 2 "x2" and an adjustment accuracy of 10% μ m

The adjustment range of the microscope in z-axis direction is 50.8 mm

With C-mount or CCD interface. After the installation of CCD, it can be observed synchronously on the display of PC Samples. At the same time, CCD can be controlled by PC to collect and record the sample image.
